What is telescopic boom lift?

The swllift telescopic boom lift utilizes a telescopic boom structure to perform building maintenance, cleaning and other tasks in restricted spaces and on the ground. One of the common types is the spider platform, which is small and lightweight and can be folded into a standard single door size of 0.8 meters wide and 2 meters high. It puts very little pressure on the ground and is particularly suitable for working on tiled and marble floors inside buildings.

The telescopic boom lift for sale has a multi-directional support leg system that allows independent adjustment of the vertical and horizontal position of the legs. Automatic stabilizing operating system ensures maximum working height and maximum safety factor. The advanced auto-propulsion driving system allows operation and control in limited spaces. The work basket can be rotated 75 degrees left or right and the work arm can perform 360 degrees of continuous rotation. The automatic safety maneuvering system ensures that the maximum working height can be reached safely even when the outriggers are in different planes. The design of the slewing boom and telescopic boom gives the product a maximum working range.

The telescopic boom lift price is equipped with four independent hydraulic support legs, which can be adapted to operate on uneven floors and stairs. Suitable for indoor operation. The floor chassis and the work basket are equipped with a control console. The basket is equipped with an automatic leveling system and hydraulic left/right rotation. The console inside the work basket can control various movements of the arm. The ground console is a portable console that can control various movements of the arm, traveler and support foot. An emergency hand pump is also provided to manually operate the unit when a power source is not available. The support legs are equipped with automatic load controllers that detect the pressure against the ground in real time. As a result, the limitation of the lateral reach of the lift arms by each support foot helps to maintain the balance of the machine in different positions.

The swllift telescopic boom lift is equipped with fast/slow speed, forward/backward direction selection and left/right steering. The overall fuselage width can be reduced to less than 1 meter for easy passage through narrow gates. The maximum traveling speed is typically 2 km/h and the climbing capacity is 20% (about 11 degrees). A specially designed work basket allows the user to quickly mount and dismount the platform for smaller transport widths. Two independent power systems are usually available: 24V DC and 220V AC. The lift arm will not raise when the support feet are not fully supporting the body. After the lift arm is raised, the support feet will be locked and cannot be recovered. The floor console, work basket console and body are equipped with an emergency stop device. The platform has a self-propelled function when the lift arms and support feet are in a retracted state.
